2005 Volkswagen Passat Variant 2.0 FSI Turbo Automatic

Car Specs

2005 Volkswagen Passat Variant 2.0 FSI Turbo Automatic

Information

Volkswagen

Quick Facts

Build Start: 2005

Available in other variants

read more »

Specifications

General

Build Start: 2005
Model Variant: Passat

Dimensions

Wheelbase: 2709mm
Track/tread (rear): 1551mm
Width: 1820mm
Fuel Tank Capacity: 70litres
Track/tread (front): 1552mm
Length: 4774mm
Height: 1517mm
Kerb weight: 1518kg

Body Details

Body Type: 4/5 seater estate/station wagon

Engine Details

Engine Layout: transverse
Engine Type: turbocharged petrol
Cylinders: Straight 4
Bore × Stroke: 82.5 × 92.8mm
Top Gear Ratio: 0.73
Specific output: 99.3bhp/litre
Specific torque: 141.13Nm/litre
Sump: wet sumped
Crankshaft Bearings: 5
Catalytic converter: Y
Engine Position: front
Engine Manufacturer: Volkswagen
Capacity: 2 litre (1984cc)
Gearbox: 6 speed automatic
Bore/stroke ratio: 0.89
Final Drive Ratio: 3.87
Engine Construction: aluminium alloy block; aluminium head
Compression Ratio: 10.3:1
Engine Coolant: Water
Aspiration: Turbo

Performance

Power-to-weight ratio: 131.58 PS/tonne (1000 kg)
Acceleration 0-100km/h: 7.8s
Standing kilometre: 28.5 s
Weight-to-power ratio: 10.33kg/kW
Drive Wheels: front wheel drive
Maximum Power Output: 200 @ 5100 rpm
Maximum Torque: 280 Nmlb/ft
Acceleration 0-80km/h (50mph): 5.5s
Standing quarter-mile: 15.7 s
Maximum Speed: 227km/h

Our Sponsor

Fuel Consump.

Fuel Consumption: 12.8/6.8/9.0 l/100km urban/extra-urban/combined
VED band (UK): K
Fuel system: direct petrol injection
Carbon dioxide emissions: 216.0 g/km NEDC

Chassis & Geomtry

Length:Wheelbase Ratio: 1.76
Front Suspension: I.MS.LW.ARB.
Rear suspension: I.4Li.ARB.

Brakes

Brakes F/R: VeDi/Di-S-ABS
Rear brake diameter: 286mm
Front Brake Diameter: 312mm
bmep (brake mean effective pressure): 1773.5kPa

Wheels & Tyres

Wheel Size Front: 16x7J
Tyres Front: 215/55 R 16 W
Wheel Size Rear: 16x7J
Tyres Rear: 215/55 R 16 W

Aerodynamics

Frontal area: 2.29 m²
Drag coefficient: 0.3
CdA: 0.69

Other

Valve Gear: double overhead camshaft (DOHC), 4 valves per cylinder, 16 valves in total
RAC rating: 16.9
Unitary Capacity: 496cc
Number of doors: 5
