2003 Alfa Romeo 156 2.4 JTD Multijet

Car Specs

2003 Alfa Romeo 156 2.4 JTD Multijet

Information

Alfa Romeo

Quick Facts

Build Start: 2003

Available in other variants

read more »

Specifications

General

Build Start: 2003
Model Variant: 156

Dimensions

Track/tread (front): 1511mm
Length: 4435mm
Height: 1430mm
Kerb weight: 1385kg
Wheelbase: 2595mm
Track/tread (rear): 1498mm
Width: 1743mm
Fuel Tank Capacity: 63litres

Body Details

Body Type: 4/5 seater sedan/saloon

Engine Details

Cylinders: Straight 5
Bore × Stroke: 82 × 90.4mm
Gearbox: 6 speed manual
Final Drive Ratio: 3.55
Engine Coolant: Water
Aspiration: Turbo D.
Intercooler: Y
Engine Position: front
Engine Type: turbocharged diesel
Engine Manufacturer: Fiat
Capacity: 2.4 litre (2387cc)
Bore/stroke ratio: 0.91
Top Gear Ratio: 0.62
Compression Ratio: 18.45:1
Compressor: Variable geometry turbocharger
Catalytic converter: Y
Engine Layout: transverse

Performance

Acceleration 0-80km/h (50mph): 6s
Acceleration 0-100km/h: 8.3s
Standing quarter-mile: 16.4 s, @ 90 mph
Maximum Speed: 216km/h
Weight-to-power ratio: 10.8kg/kW
Drive Wheels: front wheel drive
Acceleration 0-60mph: 7.6s
Acceleration 0-160km/h (100mph): 20.4s
Standing kilometre: 29.1 s, @ 183 km/h
Power-to-weight ratio: 125.91 PS/tonne (1000 kg)

Our Sponsor

Fuel Consump.

Fuel system: Multijet direct diesel inj.
Carbon dioxide emissions: 175.0 g/km NEDC
Fuel Consumption: 8.8/5.3/6.6 l/100km urban/extra-urban/combined
VED band (UK): H

Chassis & Geomtry

Turning Circle: 11.60 m
Rear suspension: I.MS.ARB.
Length:Wheelbase Ratio: 1.71
Front Suspension: I.DW.ARB.

Brakes

Front Brake Diameter: 284mm
Brakes F/R: VeDi/Di-S
Rear brake diameter: 276mm
bmep (brake mean effective pressure): 2026.8kPa

Wheels & Tyres

Wheel Size Rear: 16x6½J
Tyres Rear: 205/60 15
Tyres Front: 205/60 15
Wheel Size Front: 16x6½J

Other

Valve Gear: double overhead camshaft (DOHC), 4 valves per cylinder, 20 valves in total
Specific output(CEE): 72.1 bhp/litre1.18 bhp/cu in
Specific torque(CEE): 161.29 Nm/litre, 1.95 ft·lb/cu3
Designer: Giugiaro
maximum power output(CEE): 174 PS (172 bhp) (128 kW)at 4000 rpm
maximum torque(CEE): 385 Nm (284 ft·lb) (39.3 kgm)at 2000 rpm
RAC rating: 20.8
Unitary Capacity: 477.4cc
Number of doors: 4
Steering: power assisted rack & pinion
