2002 Alfa Romeo 156 1.9 JTD

Specifiche dell'auto

2002 Alfa Romeo 156 1.9 JTD

Informazione

Alfa Romeo

Quick Facts

Build Start: 2002

Available in other variants

read more »

Specifiche

General

Build Start: 2002
Model Variant: 156

Dimensions

Fuel Tank Capacity: 63litres
Wheelbase: 2595mm
Track/tread (rear): 1506mm
Width: 1745mm
Kerb weight: 1305kg
Track/tread (front): 1519mm
Length: 4430mm
Height: 1415mm

Body Details

Body Type: 4/5 seater sedan/saloon

Engine Details

Gearbox: 5 speed manual
Final Drive Ratio: 3.35
Engine Manufacturer: Alfa Romeo
Capacity: 1.9 litre (1910cc)
Bore/stroke ratio: 0.91
Compression Ratio: 18.45:1
Catalytic converter: Y
Engine Position: front
Top Gear Ratio: 0.76
Engine Type: turbocharged diesel
Cylinders: Straight 4
Bore × Stroke: 82 × 90.4mm
Engine Coolant: Water
Aspiration: Turbo D.
Engine Layout: transverse

Performance

Standing kilometre: 32.6 s
Power-to-weight ratio: 87.79 PS/tonne (1000 kg)
Drive Wheels: front wheel drive
Acceleration 0-100km/h: 10.3s
Maximum Speed: 191km/h
Weight-to-power ratio: 15.49kg/kW

Our Sponsor

Fuel Consump.

Carbon dioxide emissions: 155.0 g/km NEDC
Fuel system: Direct diesel inj.
VED band (UK): G

Chassis & Geomtry

Length:Wheelbase Ratio: 1.71
Turning Circle: 11.60 m
Rear suspension: I.MS.ARB.
Front Suspension: I.DW.ARB.

Brakes

bmep (brake mean effective pressure): 1809.3kPa
Front Brake Diameter: 281mm
Rear brake diameter: 251mm
Brakes F/R: Di/Di-S

Wheels & Tyres

Tyres Rear: 185/65 15
Tyres Front: 185/65 15

Other

maximum power output(CEE): 115 PS (113 bhp) (84 kW)at 4000 rpm
maximum torque(CEE): 275 Nm (203 ft·lb) (28 kgm)at 2000 rpm
Unitary Capacity: 477.5cc
RAC rating: 16.7
Valve Gear: single overhead camshaft (SOHC), 2 valves per cylinder, 8 valves in total
Specific output(CEE): 59.2 bhp/litre0.97 bhp/cu in
Specific torque(CEE): 143.98 Nm/litre, 1.74 ft·lb/cu3
Steering: power assisted rack & pinion
Number of doors: 4
