2002 Alfa Romeo 156 1.9 JTD

Car Specs

2002 Alfa Romeo 156 1.9 JTD

Information

Alfa Romeo

Quick Facts

Build Start: 2002

Available in other variants

read more »

Specifications

General

Build Start: 2002
Model Variant: 156

Dimensions

Wheelbase: 2595mm
Track/tread (rear): 1506mm
Width: 1745mm
Fuel Tank Capacity: 63litres
Track/tread (front): 1519mm
Length: 4430mm
Height: 1415mm
Kerb weight: 1305kg

Body Details

Body Type: 4/5 seater sedan/saloon

Engine Details

Engine Coolant: Water
Aspiration: Turbo D.
Catalytic converter: Y
Engine Layout: transverse
Gearbox: 6 speed manual
Final Drive Ratio: 3.56
Cylinders: Straight 4
Bore × Stroke: 82 × 90.4mm
Compression Ratio: 18:1
Intercooler: Y
Engine Position: front
Top Gear Ratio: 0.61
Engine Type: turbocharged diesel
Capacity: 1.9 litre (1910cc)
Bore/stroke ratio: 0.91

Performance

Standing kilometre: 31 s
Power-to-weight ratio: 107.22 PS/tonne (1000 kg)
Acceleration 0-100km/h: 9.3s
Maximum Speed: 209km/h
Weight-to-power ratio: 12.68kg/kW
Drive Wheels: front wheel drive

Our Sponsor

Fuel Consump.

Fuel system: Bo EDC 16 direct diesel inj.
Fuel Consumption: 8.0/4.7/5.9 l/100km urban/extra-urban/combined
VED band (UK): G
Carbon dioxide emissions: 157.0 g/km NEDC

Chassis & Geomtry

Front Suspension: I.DW.TA.ARB.
Length:Wheelbase Ratio: 1.71
Turning Circle: 11.60 m
Rear suspension: I.MS.ARB.

Brakes

Front Brake Diameter: 281mm
bmep (brake mean effective pressure): 2006.7kPa
Rear brake diameter: 276mm

Wheels & Tyres

Tyres Front: 185/65 HR 15
Tyres Rear: 185/65 HR 15

Other

Specific torque(EC): 159.69 Nm/litre, 1.93 ft·lb/cu3
Steering: power assisted rack & pinion
Valve Gear: double overhead camshaft (DOHC), 4 valves per cylinder, 16 valves in total
Specific output(EC): 72.3 bhp/litre1.18 bhp/cu in
Unitary Capacity: 477.5cc
Number of doors: 4
RAC rating: 16.7
maximum power output(EC): 140 PS (138 bhp) (103 kW)at 4000 rpm
maximum torque(EC): 305 Nm (225 ft·lb) (31.1 kgm)at 2000 rpm
