1998 Alfa Romeo 166 2.4 JTD

Autospecificaties

1998 Alfa Romeo 166 2.4 JTD

Informatie

Alfa Romeo

Quick Facts

Build Start: 1998

Available in other variants

read more »

Specificaties

General

Build Start: 1998
Model Variant: 166

Dimensions

Wheelbase: 2700mm
Track/tread (rear): 1532mm
Width: 1815mm
Fuel Tank Capacity: 72litres
Track/tread (front): 1545mm
Length: 4720mm
Height: 1416mm
Kerb weight: 1490kg

Body Details

Body Type: 4/5 seater sedan/saloon

Engine Details

Engine Layout: transverse
Top Gear Ratio: 0.61
Cylinders: Straight 5
Bore × Stroke: 82 × 90.4mm
Specific output(DIN): 56.1 bhp/litre0.92 bhp/cu in
Specific torque(DIN): 127.36 Nm/litre, 1.54 ft·lb/cu3
Compression Ratio: 18.45:1
Compressor: 1 Garrett VNT 25 turbo
Catalytic converter: Y
Engine Position: front
Gearbox: 6 speed manual
Engine Type: turbocharged diesel
Final Drive Ratio: 3.56
Capacity: 2.4 litre (2387cc)
Bore/stroke ratio: 0.91
Sump: wet sumped
Engine Coolant: Water
Aspiration: Turbo D.
Intercooler: Y

Performance

Standing kilometre: 31.7 s
Power-to-weight ratio: 91.18 PS/tonne (1000 kg)
Weight-to-power ratio: 14.91kg/kW
Drive Wheels: front wheel drive
maximum power output(DIN): 136 PS (134 bhp) (100 kW)at 4000 rpm
maximum torque(DIN): 304 Nm (224 ft·lb) (31 kgm)at 2000 rpm
Acceleration 0-100km/h: 9.9s
Maximum Speed: 202km/h

Our Sponsor

Fuel Consump.

Fuel Consumption: 9.9/5.7/7.3 l/100km urban/extra-urban/combined
Fuel system: Bo EDC 15 diesel inj.

Chassis & Geomtry

Front Suspension: I.DW.CS.ARB.
Length:Wheelbase Ratio: 1.75
Turning Circle: 11.60 m
Rear suspension: I.MultiLi.LW.CS.ARB.

Brakes

Brakes F/R: VeDi/Di-S-ABS
Rear brake diameter: 276mm
bmep (brake mean effective pressure): 1600.4kPa
Front Brake Diameter: 281mm

Wheels & Tyres

Tyres Front: 205/55 WR 16
Tyres Rear: 205/55 WR 16

Other

Steering: power assisted rack & pinion
RAC rating: 20.8
Valve Gear: single overhead camshaft (SOHC), 2 valves per cylinder, 10 valves in total
Unitary Capacity: 477.4cc
Number of doors: 4
