1978 Alfa Romeo Giulietta 1.6

Car Specs

1978 Alfa Romeo Giulietta 1.6

Information

Alfa Romeo

Quick Facts

Build Start: 1978

Available in other variants

read more »

Specifications

General

Build Start: 1978
Model Variant: Giulietta

Dimensions

Kerb weight: 1071kg
Wheelbase: 2510mm
Track/tread (rear): 1360mm
Width: 1650mm
Ground clearance: 140mm
Fuel Tank Capacity: 50litres
Track/tread (front): 1360mm
Length: 4210mm
Height: 1400mm

Body Details

Body Type: 4/5 seater sedan/saloon

Engine Details

Engine Type: naturally aspirated petrol
Cylinders: Straight 4
Gearbox: 5 speed manual
Bore × Stroke: 78 × 82mm
Final Drive Ratio: 4.30
Specific output(DIN): 68.2 bhp/litre1.12 bhp/cu in
Specific torque(DIN): 91.08 Nm/litre, 1.1 ft·lb/cu3
Sump: wet sumped
Engine Coolant: Water
Aspiration: Normal
Engine Position: front
Engine Manufacturer: Alfa Romeo
Capacity: 1.6 litre (1570cc)
Top Gear Ratio: 0.83
Bore/stroke ratio: 0.95
Engine Construction: light alloy block & head
Compression Ratio: 9:1
Crankshaft Bearings: 5
Catalytic converter: N
Engine Layout: longitudinal

Performance

Maximum RPM: 5800rpm
Standing quarter-mile: 17.6 s
Power-to-weight ratio: 101.3 PS/tonne (1000 kg)
Drive Wheels: rear wheel drive
maximum power output(DIN): 108 PS (107 bhp) (80 kW)at 5600 rpm
maximum torque(DIN): 143 Nm (105 ft·lb) (14.6 kgm)at 4300 rpm
Maximum Speed: 175km/h
Weight-to-power ratio: 13.42kg/kW

Fuel Consump.

Fuel system: 2 De DHLA 40H carbs

Chassis & Geomtry

Turns Lock-to-Lock: 3.500
Front Suspension: I.W.TB.ARB.
Turning Circle: 10.90 m
Rear suspension: dD.TA.WL.CS.ARB.
Length:Wheelbase Ratio: 1.68

Brakes

Brakes F/R: Di/Di-S
Rear brake diameter: 250mm
Front Brake Diameter: 250mm
Braked area: 2128 cm2
bmep (brake mean effective pressure): 1144.6kPa

Wheels & Tyres

Wheel Size Front: 13x5.0
Tyres Front: 165 SR 13
Wheel Size Rear: 13x5.0
Tyres Rear: 165 SR 13

Other

Valve Gear: double overhead camshaft (DOHC), 2 valves per cylinder, 8 valves in total
RAC rating: 15.1
Unitary Capacity: 392.5cc
Number of doors: 4
Steering: rack & pinion
