2010 Acura TSX Wagon Automatic

Car Specs

2010 Acura TSX Wagon Automatic

Information

Acura

Quick Facts

Build Start: 2010

Available in other variants

read more »

Specifications

General

Build Start: 2010
Model Variant: TSX

Dimensions

Wheelbase: 2705 mmmm
Track/tread (rear): 1580 mmmm
Width: 1840mm
Ground clearance: 150 mmmm
Kerb weight: 1633kg
Fuel Tank Capacity: 70litres
Track/tread (front): 1580 mmmm
Length: 4805mm
Height: 1470mm

Body Details

Body Type: 4/5 seater estate/station wagon

Engine Details

Bore/stroke ratio: 0.88
Engine Construction: aluminium alloy block & head
Compression Ratio: 11:1
Engine Coolant: Water
Aspiration: Normal
Engine Layout: transverse
Gearbox: 5 speed automatic
Final Drive Ratio: 4.44
Engine Manufacturer: Honda
Capacity: 2.4 litre (2354 cc)
Specific output: 85.4bhp/litre
Specific torque: 98.13Nm/litre
Sump: wet sumped
Catalytic converter: Y
Engine Position: front
Top Gear Ratio: 0.57
Engine Type: naturally aspirated petrol
Cylinders: Straight 4
Bore × Stroke: 87 × 99mm

Performance

Maximum Power Output: 204 PS (201 bhp) (150 kW)at 7000 rpm
Maximum Torque: 231 Nm (170 ft·lb) (23.6 kgm)at 4300 rpmlb/ft
Power-to-weight ratio: 124.8 PS/tonne (1000 kg), 0.12 PS/kg, 91.79 kW/tonne (1000 kg), 0.09 kW/kg, 123.09 bhp/tonne (1000 kg), 0.12 bhp/kg, 0.05 bhp/lb
Maximum RPM: 7100 rpmrpm
Weight-to-power ratio: 10.89 kg/kW, 18.2 lb/bhpkg/kW
Drive Wheels: front wheel drive

Our Sponsor

Fuel Consump.

Fuel Consumption: 22/30/25 US MPG EPA city/highway/combined
Fuel system: Honda PGM-Fi fuel injection

Chassis & Geomtry

Turns Lock-to-Lock: 2.610
Rear suspension: I.MultiLi.DW.CS.ARB.
Front Suspension: I.DW.CS.ARB.
Length:Wheelbase Ratio: 1.78
Weight Distribution: 57% front

Brakes

bmep (brake mean effective pressure): 1233.1 kPa (178.9 psi)kPa
Front Brake Diameter: 300 mmmm
Brakes F/R: VeDi/Di-S-ABS
Rear brake diameter: 282 mmmm

Wheels & Tyres

Wheel Size Rear: 17x7½
Tyres Rear: Michelin Pilot HX MXM4 P225/50 R 17 93V
Wheel Size Front: 17x7½
Tyres Front: Michelin Pilot HX MXM4 P225/50 R 17 93V

Other

Valve Gear: double overhead camshaft (DOHC), 4 valves per cylinder, 16 valves in total
Unitary Capacity: 588.5cc
Number of doors: 5
RAC rating: 18.8
