2009 Acura TSX V6

Car Specs

2009 Acura TSX V6

Information

Acura

Quick Facts

Build Start: 2009

Available in other variants

read more »

Specifications

General

Build Start: 2009
Model Variant: TSX

Dimensions

Ground clearance: 145 mmmm
Kerb weight: 1669kg
Fuel Tank Capacity: 70litres
Wheelbase: 2705 mmmm
Track/tread (rear): 1582 mmmm
Width: 1840mm
Track/tread (front): 1581 mmmm
Length: 4726mm
Height: 1440mm

Body Details

Body Type: 4/5 seater sedan/saloon

Engine Details

Gearbox: 5 speed automatic
Final Drive Ratio: 4.31
Engine Manufacturer: Honda
Capacity: 3.5 litre (3471 cc)
Bore/stroke ratio: 0.96
Engine Construction: aluminium alloy block & head
Compression Ratio: 11.2:1
Engine Coolant: Water
Aspiration: Normal
Engine Layout: transverse
Top Gear Ratio: 0.49
Engine Type: naturally aspirated petrol
Cylinders: V 6 in 60° vee
Bore × Stroke: 89 × 93mm
Specific output: 80.7bhp/litre
Specific torque: 99.39Nm/litre
Sump: wet sumped
Catalytic converter: Y
Engine Position: front

Performance

Maximum Power Output: 284 PS (280 bhp) (209 kW)at 6200 rpm
Maximum Torque: 345 Nm (254 ft·lb) (35.2 kgm)at 5000 rpmlb/ft
Power-to-weight ratio: 170.1 PS/tonne (1000 kg), 0.17 PS/kg, 125.1 kW/tonne (1000 kg), 0.13 kW/kg, 167.77 bhp/tonne (1000 kg), 0.17 bhp/kg, 0.07 bhp/lb
Maximum RPM: 6800 rpmrpm
Weight-to-power ratio: 7.99 kg/kW, 13.35 lb/bhpkg/kW
Drive Wheels: front wheel drive

Our Sponsor

Fuel Consump.

Fuel Consumption: 20/28/23 US MPG EPA city/highway/combined
Fuel system: Honda PGM-Fi fuel injection

Chassis & Geomtry

Turns Lock-to-Lock: 2.510
Rear suspension: I.MultiLi.DW.CS.ARB.
Length:Wheelbase Ratio: 1.75
Weight Distribution: 62% front
Front Suspension: I.DW.CS.ARB.

Brakes

Front Brake Diameter: 300 mmmm
bmep (brake mean effective pressure): 1249 kPa (181.2 psi)kPa
Brakes F/R: VeDi/Di-S-ABS
Rear brake diameter: 282 mmmm

Wheels & Tyres

Wheel Size Rear: 18x8.0
Tyres Rear: Michelin Pilot HX MXM4 P235/45 R 18 94V
Wheel Size Front: 18x8.0
Tyres Front: Michelin Pilot HX MXM4 P235/45 R 18 94V

Other

RAC rating: 29.5
Valve Gear: single overhead camshaft (SOHC), 4 valves per cylinder, 24 valves in total
Unitary Capacity: 578.5cc
Number of doors: 4
